The American Panel Corporation 10X20-O is a versatile walk-in combination cooler and freezer designed for outdoor use, featuring a 50/50 split configuration. With dimensions of 7'-6" H x 19'-3" W x 9'-8" D, it offers ample storage space for perishable goods. The cooler section is floorless on a vinyl screed, while the freezer boasts durable foamed-in-place 4" urethane floor panels for enhanced insulation.
Constructed with acrylume for both interior and exterior surfaces, this unit ensures durability and easy maintenance. It includes a hinged door equipped with camlift hinges for smooth operation, a dial thermometer for accurate temperature monitoring, and a vapor-proof light for visibility in all conditions.
The refrigeration system features a 2-1/2 HP low-temperature freezer capable of reaching -10°F and a 3/4 HP medium-temperature cooler maintaining 35°F. Both sections utilize a hermetic pre-charged remote quick-connect R448 refrigeration system. The cooler's condensing unit operates at 208v/60/1-ph with a current draw of 12.7 amps, while the freezer's condensing unit operates at the same voltage with a higher current draw of 21.7 amps. The evaporators for both sections are designed for efficiency, with the cooler drawing 1 amp and the freezer drawing 1.4 amps for fans and 8.2 amps for heaters.
Additional features include winterization controls and a Heatcraft Quick Response Controller as standard, ensuring optimal performance in varying conditions. This combination cooler/freezer is ideal for businesses requiring reliable temperature control for a wide range of products.
